Round Spindle Fixture 100mm Dia
Spindle motor holder for 100 mm diameter spindles, for mounting the spindle to the Z axis.
Overview
A clamp for mounting a 100 mm diameter spindle motor to a machine's Z axis.
The number that matters is the body diameter, not the power. Spindles of quite different power ratings share a body diameter, and spindles of the same power come in different diameters — so measure the spindle you actually have, or check its stated body diameter, before choosing a clamp. A holder that does not match will not grip, and packing it out is not a fix on a part that carries all the cutting load.
The clamp is the mechanical link between the cutting forces and the machine. Its rigidity sets how much the spindle deflects under load, which shows up directly as finish quality and cut accuracy.
For other spindle diameters, see the rest of the Spindle Holder range.
Supplied by Tiny Controls in India.
Specifications
| Spindle diameter | 100 mm |
|---|---|
| Type | Round clamp |
| Function | Spindle to Z-axis mounting |
Questions
Which clamp size do I need?
The one matching your spindle's body diameter, which is not related to its power rating. Measure the spindle body or check its specification before ordering.
Will it fit my Z axis?
The mounting hole pattern is not stated in our record. Send us your Z-axis plate details and we will confirm before you order.
What is it made from?
The material is not stated in our record. Please ask — it affects rigidity, and rigidity affects cut quality.
