Spindle Motor clamp : 62 holding dia
Spindle motor holder for 62 mm diameter spindles, for mounting the spindle to the Z axis.
Overview
A clamp for mounting a 62 mm diameter spindle motor to a machine's Z axis.
The number that matters is the body diameter, not the power. Spindles of quite different power ratings share a body diameter, and spindles of the same power come in different diameters, so measure the spindle you actually have, or check its stated body diameter, before choosing a clamp. A holder that does not match will not grip, and packing it out is not a fix on a part that carries all the cutting load. This catalogue's TS-13 water-cooled spindle is 62 mm diameter and fits this clamp.
The clamp is the mechanical link between the cutting forces and the machine. Its rigidity sets how much the spindle deflects under load, which shows up directly as finish quality and cut accuracy.
For other spindle diameters, see the rest of the Spindle Holder range.
Supplied by Tiny Controls in India.
Specifications
| Spindle diameter | 62 mm |
|---|---|
| Function | Spindle to Z-axis mounting |
Questions
Does clamp rigidity actually affect my cut finish?
Yes — it's the mechanical link between cutting forces and the machine, and its rigidity sets how much the spindle deflects under load, which shows up directly in finish quality and cut accuracy.
What if 62mm isn't the right size for my spindle?
The rest of the Spindle Holder range covers other diameters.
Should I be matching this to my spindle's power rating or its physical size?
Physical size — body diameter, not power. Measure the spindle you actually have, or check its stated body diameter, rather than going by wattage.
